Details
Airflow m³/h
76m³/h
Applicable Area
Bathroom, Laundry Room, Toilet
Backdraft Shutter
No
Extraction Rate
21L/s
Extractor Fan Type
Axial
Fan Diameter
4 Inch
Finish/Colour
White
GTIN (Barcode)
5013562930024
IP Rating
IPX4
MPN
93002AW
Min Voltage
220V
Mounting Options
Ceiling, Wall, Window
Number of Speeds
2
Pull Cord
Yes
Voltage
240V
Dimensions
Height
179mm
Width
179mm
Xpelair 93002AW Simply Silent DX100BPS Pullcord Square Intermittent Extractor Fan
SKU: 93002AW
Buy more, save more!
| Quantity | Price | Saving Per Item |
|---|---|---|
| 10+ | £29.36 | Save 2% |
| 20+ | £28.76 | Save 4% |
| 30+ | £28.16 | Save 6% |
You may also need
Details
Airflow m³/h
76m³/h
Applicable Area
Bathroom, Laundry Room, Toilet
Backdraft Shutter
No
Extraction Rate
21L/s
Extractor Fan Type
Axial
Fan Diameter
4 Inch
Finish/Colour
White
GTIN (Barcode)
5013562930024
IP Rating
IPX4
MPN
93002AW
Min Voltage
220V
Mounting Options
Ceiling, Wall, Window
Number of Speeds
2
Pull Cord
Yes
Voltage
240V
Dimensions
Height
179mm
Width
179mm
Product Information
The Simply Silent DX100B two-speed, intermittent extractor fans are supplied as fan-only units and are ideal for replacement installation in bathrooms, shower rooms, cloakrooms and toilets. Just like the entire Simply Silent family, these fans control humidity, odours and mould growth, are finished in cool white and available in either round or square.
Features:
- Extremely quiet running - only 22dBA@3M at low speed
- Stylish traditional grille design available in square and round
- 2 speeds 15l/s and 21l/s - selectable at install
- Suitable for wall, ceiling, panel and window fitting
- Complies with building regulations Part F and L
Specifications:
- Electrical power rating (W): 6.7 / 7.7
- Extract performance (FID, M³/h) Max/Min: 54 / 76
- Extract performance (FID, l/s) Max/Min: 15 / 21
- Sound pressure level db(A)@3m: 22 / 34
- Specific Fan Power (SFP) (W/l/s): 0.45 / 0.37
- Operation Speeds: 2
- UK Guarantee: 2 Years
- IPX Rating: 4
- Pullcord: Yes
Criteria
- Warranty: 2 Years
- Manufacturer Code: 93002AW
- Barcode: 5013562930024
