Details
Applicable Area
Home
Cable Accessory Type
Junction Boxes
Cable Entry Options
Variable Knockout Sizes
Colour
Black
Current
32A
Domestic/Commercial
Domestic
Finish/Colour
Black
GTIN (Barcode)
4007685605809
IP Rating
IP66
MPN
10060580
Material
Polypropylene
Max Storage Temp
100°C
Min Storage Temp
-30°C
Voltage
400V
Is Waterproof
Yes
Dimensions
Depth
51mm
Height
85mm
Weight
0.1kg
Width
85mm
Wiska COMBI 308/5 IP66 Junction Box With 5-Pole Terminals Black- 10060580
SKU: 10060580
Buy more, save more!
| Quantity | Price | Saving Per Item |
|---|---|---|
| 30+ | £4.46 | Save 1% |
| 60+ | £4.41 | Save 2% |
| 90+ | £4.37 | Save 3% |
You may also need
Details
Applicable Area
Home
Cable Accessory Type
Junction Boxes
Cable Entry Options
Variable Knockout Sizes
Colour
Black
Current
32A
Domestic/Commercial
Domestic
Finish/Colour
Black
GTIN (Barcode)
4007685605809
IP Rating
IP66
MPN
10060580
Material
Polypropylene
Max Storage Temp
100°C
Min Storage Temp
-30°C
Voltage
400V
Is Waterproof
Yes
Dimensions
Depth
51mm
Height
85mm
Weight
0.1kg
Width
85mm
Product Information
Wiska COMBI 308/5 IP66 Junction Box With 5-Pole Terminals Black- 10060580
The Wiska COMBI IP66/67 Weatherproof Junction Box range is resistant to ultraviolet, shatter-proof, impact-resistant, and eminently suitable for extreme conditions or outdoor installations. The Weatherproof Junction Box is Flame-retardent and halogen-free, highly resistant to animal or vegetable fats, mineral oil, diesel, weak acids, strong and weak alkaline solution, and alcohol.
The COMBI 308/5 has 10% more room inside thanks to the bellied cover plus is comes with rust-free quick-release lid screws of plastic, closing the box with only a quarter turn.
COMBI 308 Boxes have an integrated thread into which cable glands can be directly mounted into without locknuts. The patented combination of thread and membrane saves you one further working process.
Specification
- Protection class to EN 60 529: IP 66
- Flame protection: Glow wire test 750 degrees acc. to EN 60695-2-11
- Temperature range: -30 degrees up to 100 degrees, intermittent up to approx. 120 DegreeC
- Voltage: 400 V
- Material: Polypropylene, reinforced glass fiber; Sealing: thermoplastic elastomere
- Terminals/poles: 4 mm Degree
- Fixing: With mounting clip or 4 internal openings outside of the sealing area:
- 8 elastic self-sealing membranes for cable entry without mechanical devices
- 8 integrated M 20 threads, no locknuts necessary
- 4 captive quick-release lid screws
- Incl. mounting clip for snap-on fixing
- Colour RAL 7035 Black
Features
- IP Rated: IP67/IP68
- 8 elastic self-sealing cable inlets (clamping range 3-12 mm)
- Integrated M 20 threads, for cable glands no locknuts necessary
- 4 quick-release lid screws in the cover
- Fixing with the fast mounting clip or internally located openings out of the sealing area
- Includes 5-pole screw terminal 4 mm2 (patented)
- 10% more room inside, thanks to the bellied cover
- 30% saving on labor thanks to faster cable-entry
- Captive quick-release lid screws
