Details
Applicable Area
Bathroom, Commercial, Laundry Room, Office, Toilet, Warehouse
Collection Name
ACM
Duct Diameter
125mm
Extractor Fan Type
Inline
Fan Diameter
5 Inch
Finish/Colour
White
GTIN (Barcode)
5015135093976
IP Rating
IPX4
MPN
17105010
Mounting Options
Ceiling
Max Noise Level
25dB
Number of Speeds
3
Power Consumption
30W
Voltage
240V
Dimensions
Depth
230mm
Height
210mm
Width
230mm
Downloads
17105010-product-manual
Vent-Axia ACM125 Inline Mixed Flow Fan - 17105010
SKU: 17105010
You may also need
Details
Applicable Area
Bathroom, Commercial, Laundry Room, Office, Toilet, Warehouse
Collection Name
ACM
Duct Diameter
125mm
Extractor Fan Type
Inline
Fan Diameter
5 Inch
Finish/Colour
White
GTIN (Barcode)
5015135093976
IP Rating
IPX4
MPN
17105010
Mounting Options
Ceiling
Max Noise Level
25dB
Number of Speeds
3
Power Consumption
30W
Voltage
240V
Dimensions
Depth
230mm
Height
210mm
Width
230mm
Downloads
17105010-product-manual
Product Information
Vent-Axia has designed a complete range of Mixed Flow In-Line fans that are now quieter than any other product on the market. The impeller blade design with guide vanes provides optimum pressure characteristics and simple connectivity and quieter more efficient running provides the complete solution. The product is mounted using two straps that secure the motor chassis assembly to the footplate. The ACM Mixed Flow In-Line fan can operate in both horizontal and vertical positions and can be mounted to meet its optimum performance.
All motors are fitted with Standard Thermal Overload Protection. (S.T.O.P.). There is an adjustable minimum speed setting. The controller is radio suppressed to BS EN 55014 and electrical connections for use with suitable external sensors are provided. 86 x 156 x 53mm (H x W x D).
Delivery Information
Free Delivery on All Orders Over £50.
This Excludes Delivery to the Scottish Highlands, Offshore Islands and Northern Ireland.
For more information, please see our Delivery details.
