Details
Airflow m³/h
500m³/h
Auto Restart
Yes
BTU
9000
Dehumidifying Function
Yes
Finish/Colour
White
Fixed or Portable
Fixed
For Conservatories up to
12m²
For Rooms up to
25m²
GTIN (Barcode)
2251210230925
Heating Function
No
Installation Information
Any Installation not Completed by a Qualified F-Gas Engineer Will Invalidate the Product Warranty
LCD Display
Yes
MPN
KFR-23IW
Max Set Temperature
32°C
Min Set Temperature
16°C
Min Voltage
220V
Mounting Options
Wall
Max Noise Level
63dB
Max Noise Level (Indoor Unit)
47dB
Min Noise Level
38dB
Min Noise Level (Indoor Unit)
38dB
Pipe Supplied
Yes
Power Consumption
670W
Refrigerant
R32
Remote Control
Yes (Supplied)
Running Costs Per Hour (Approx.)
20.1p
Smart Compatible
Yes
Smart Compatible Devices
Amazon Alexa, Google Assistant
Voltage
240V
Wi-Fi Compatible
Yes
Dimensions
Depth
276mm
Depth (Outdoor Unit)
235mm
Height
202mm
Height (Outdoor Unit)
540mm
Weight
100kg
Weight (Indoor Unit)
10kg
Weight (Outdoor Unit)
25kg
Width
780mm
Width (Outdoor Unit)
715mm
Downloads
kfr-23lw
KFR-23IW/X1c Air Conditioning Unit (KFR23 Wall Split System)
SKU: KFR-23IW
Pay in 3 interest-free installments of £203.31
You may also need
Details
Airflow m³/h
500m³/h
Auto Restart
Yes
BTU
9000
Dehumidifying Function
Yes
Finish/Colour
White
Fixed or Portable
Fixed
For Conservatories up to
12m²
For Rooms up to
25m²
GTIN (Barcode)
2251210230925
Heating Function
No
Installation Information
Any Installation not Completed by a Qualified F-Gas Engineer Will Invalidate the Product Warranty
LCD Display
Yes
MPN
KFR-23IW
Max Set Temperature
32°C
Min Set Temperature
16°C
Min Voltage
220V
Mounting Options
Wall
Max Noise Level
63dB
Max Noise Level (Indoor Unit)
47dB
Min Noise Level
38dB
Min Noise Level (Indoor Unit)
38dB
Pipe Supplied
Yes
Power Consumption
670W
Refrigerant
R32
Remote Control
Yes (Supplied)
Running Costs Per Hour (Approx.)
20.1p
Smart Compatible
Yes
Smart Compatible Devices
Amazon Alexa, Google Assistant
Voltage
240V
Wi-Fi Compatible
Yes
Dimensions
Depth
276mm
Depth (Outdoor Unit)
235mm
Height
202mm
Height (Outdoor Unit)
540mm
Weight
100kg
Weight (Indoor Unit)
10kg
Weight (Outdoor Unit)
25kg
Width
780mm
Width (Outdoor Unit)
715mm
Downloads
kfr-23lw
Product Information
Replacing the KFR-23IW/X1C is the NEW and IMPROVED KFR-23IW/AG 2019 Wall Split Air Conditioning Unit Compatible With AMAZON ALEXA and GOOGLE ASSIST!
Our wall split air conditioning units are perfect for both residential and commercial use. The KFR23-IW/AG is a highly energy efficient, easy to install, multipurpose single wall split unit and can be used all year round. It will keep your home or office cool and fresh during the summer months and toasty and warm throughout the winter.
Our split system air conditioning units consist of an indoor and outdoor unit, connected via copper piping. The outdoor unit contains the condenser and removes heat and condensation from the room, dissipating it outside. All our AC units are heat pumps and are able to both heat and cool. The outdoor unit of this system can also be installed using our optional bracket kit if required.
Warranty Conditions:
Must be installed by a qualified F Gas Engineer, with Installation Certificate & receipt. Must have an annual service with a valid invoice. Copy of Installation Certificate and each annual service invoice must be lodged with us as soon as available to uphold warranty conditions.
Specification:
- Model: KFR-23IW/AG
- Power Rating (PH-V-HZ) - 1/220-240V/50Hz
- Capacity BTU/H (Cooling) KW - 9000 / 2.5 (3.3)
- Capacity BTU/H (Heating) KW - 9000 / 2.5 (3.3)
- Power Input (W) Cooling/Heating - 670-660 (1.2)
- Current Input (A) Cooling/Heating - 3.0 - 2.9
- SEER (BTU/HR.W) - 6.1
- SCOP (W/W) - 4.0
- Dehumidifactiom (L/H) - 0.9
- Noise Level DB(A) (HI/M/LO) - 38 - 47
- Noise Level DB(A) - 63
- Indoor Airflow (M3/H) (HI/MO/LO) - 500 Max
- Current Rating (A) Fuse Rating (Type D) - 7
- Net Dimensions (MM) Indoor (W/D/H) - 780x256x202
- Dimensions (MM) Outdoor (W/D/H) - 715x235x540
- Net/Gross Weight (KG) Indoor - 10
- Net/Gross Weight (KG) Outdoor - 25
- Max Room Size (m2) - 13-25
- Max Conservatory Size (m2) - 12
- Pipe Length (M) - 4
- Pipe Diameter Liquid/Gas (Inch) - 1/4 & 3/8
- Temp Range ºC - 16-32
- Operating Temp (Cooling/Heating) - -15/-10
- Restart After Power Failure - Yes
- Refrigerant Leak Detection & Self Diagnosis System - Yes
