Details
Airflow m³/h
85m³/h
Applicable Area
Bathroom, Laundry Room, Toilet
Backdraft Shutter
Yes
Collection Name
LoVolt
Duct Diameter
99mm
Extraction Rate
24L/s
Extractor Fan Type
Axial
Fan Diameter
4 Inch
Finish/Colour
White
GTIN (Barcode)
5013562908474
IP Rating
IPX5
Installation Kit
Yes
MPN
90847AW
Min Voltage
220V
Mounting Options
Ceiling, Panel, Wall, Window
Number of Speeds
1
Timer
Yes
Voltage
240V
Dimensions
Height
155mm
Lip Depth
43mm
Weight
2.2kg
Width
165mm
Downloads
xpelair-dx100-lv100-data-sheet
Xpelair LoVolt LV100T Safety Extra Low Voltage 100mm Axial Extract Fan - 90847AW
SKU: 90847AW
Buy more, save more!
| Quantity | Price | Saving Per Item |
|---|---|---|
| 10+ | £68.56 | Save 2% |
| 20+ | £67.16 | Save 4% |
| 30+ | £65.76 | Save 6% |
OUR EXPERTS RECOMMEND
You may also need
Details
Airflow m³/h
85m³/h
Applicable Area
Bathroom, Laundry Room, Toilet
Backdraft Shutter
Yes
Collection Name
LoVolt
Duct Diameter
99mm
Extraction Rate
24L/s
Extractor Fan Type
Axial
Fan Diameter
4 Inch
Finish/Colour
White
GTIN (Barcode)
5013562908474
IP Rating
IPX5
Installation Kit
Yes
MPN
90847AW
Min Voltage
220V
Mounting Options
Ceiling, Panel, Wall, Window
Number of Speeds
1
Timer
Yes
Voltage
240V
Dimensions
Height
155mm
Lip Depth
43mm
Weight
2.2kg
Width
165mm
Downloads
xpelair-dx100-lv100-data-sheet
Product Information
The Xpelair LoVolt LV100T is a compact and efficient 4"/100mm axial extract fan designed for safe and effective ventilation in bathrooms and shower rooms. This single-speed fan operates on a 12V Safety Extra Low Voltage (SELV) system, ensuring maximum safety even when installed directly in or over splash zones. The LV100T comes with a transformer that allows for secure installation, making it an ideal choice for areas prone to moisture. Its sleek white finish and universal mounting kit, which includes options for wall, ceiling, and window installations, ensure it blends seamlessly into any bathroom decor.
Equipped with an adjustable timer, the Xpelair LV100T offers customizable operation to suit your needs. The timer can be set to run from 2 to 20 minutes after being triggered by an external switch, such as a light circuit. This feature ensures that your bathroom remains well-ventilated even after you leave, helping to prevent the buildup of moisture and mold. The fan's efficient performance, with an extraction rate of 23 liters per second, ensures that your bathroom stays fresh and dry.
The Xpelair LV100T is not only functional but also easy to install. It comes with a comprehensive fitting kit that includes a telescopic wall tube, gaskets, an outer grille, and a skirt molding for window installations. This makes it versatile and suitable for various installation scenarios, whether in walls, ceilings, or single-glazed windows up to 6mm thick. With its reliable performance and safety features, the Xpelair LV100T is an excellent choice for maintaining a comfortable and healthy bathroom environment.
