Details
Airflow m³/h
90m³/h
Applicable Area
Bathroom, Kitchen, Laundry Room, Toilet
Backdraft Shutter
Yes
Extraction Rate
25L/s
Extractor Fan Type
Centrifugal
Fan Diameter
4 Inch
Finish/Colour
White
Fixed or Portable
Fixed
Fixed or Adjustable
Fixed
GTIN (Barcode)
5020953550587
Humidistat
Yes
IP Rating
IP24
Installation Kit
Yes
MPN
CF100H
Min Voltage
220V
Mounting Options
Ceiling, Wall
Number of Speeds
1
Power Consumption
17W
Timer
Yes
Voltage
240V
Dimensions
Height
163mm
Lip Depth
90mm
Weight
0.96kg
Width
163mm
Downloads
cf100-cf200-spec-sheet
Manrose CF100H 100mm 4 Centrifugal Extractor Fan with Humidistat
SKU: CF100H
Buy more, save more!
| Quantity | Price | Saving Per Item |
|---|---|---|
| 10+ | £55.82 | Save 2% |
| 20+ | £54.68 | Save 4% |
| 30+ | £53.54 | Save 6% |
OUR EXPERTS RECOMMEND
You may also need
Details
Airflow m³/h
90m³/h
Applicable Area
Bathroom, Kitchen, Laundry Room, Toilet
Backdraft Shutter
Yes
Extraction Rate
25L/s
Extractor Fan Type
Centrifugal
Fan Diameter
4 Inch
Finish/Colour
White
Fixed or Portable
Fixed
Fixed or Adjustable
Fixed
GTIN (Barcode)
5020953550587
Humidistat
Yes
IP Rating
IP24
Installation Kit
Yes
MPN
CF100H
Min Voltage
220V
Mounting Options
Ceiling, Wall
Number of Speeds
1
Power Consumption
17W
Timer
Yes
Voltage
240V
Dimensions
Height
163mm
Lip Depth
90mm
Weight
0.96kg
Width
163mm
Downloads
cf100-cf200-spec-sheet
Product Information
The Manrose CF100H Centrifugal Fan is a state-of-the-art ventilation solution designed to provide powerful, yet quiet and vibration-free airflow. Ideal for bathrooms, toilets, cloakrooms, and utility rooms, this fan is engineered to move air over long distances, ensuring maximum performance even against the pressures caused by long lengths of ducting and resistance by grilles. With an impressive extract rate of 90m³/hr (25 liters per second), the CF100H ensures a fresh and healthy environment in your home.
Each CF100H model is equipped with a built-in spring-operated non-return flap in the discharge spigot to prevent backdraughts, enhancing its efficiency and reliability. Constructed from high-impact ABS thermoplastics, these units offer exceptional strength, durability, and easy cleaning. The fan is powered by a single-phase induction motor with pre-oiled bearings, providing a long, maintenance-free life. Additionally, the CF100 complies with Building Regulations on Ventilation (F1), ensuring it meets the highest standards for safety and performance.
The CF100H features an adjustable humidistat, allowing you to control the humidity levels between 40% and 95% RH, offering customizable ventilation to suit your needs. Designed for use with 100mm (4") standard rigid or flexible ducting, this fan is double insulated and does not require an earth. With a noise level of 42.0 dB(A) and a fan speed of 1600 r.p.m., the CF100 provides efficient and quiet operation. Its compact dimensions (Height: 163mm x Width: 163mm x Depth: 90mm) make it a versatile and effective addition to any ventilation system.
