Details
Device Type
RCBO
GTIN (Barcode)
5026992046241
MPN
RCBO-32-30-SPA
Wired
No
Dimensions
Depth
76mm
Height
114mm
Weight
0.17kg
Width
18mm
Downloads
rcbo3230spa-datasheet
Lewden 32A Single Pole 1 Module B Curve 6kA 30mA Type A RCBO - RCBO-32-30-SPA
SKU: RCBO-32-30-SPA
OUR EXPERTS RECOMMEND
You may also need
Details
Device Type
RCBO
GTIN (Barcode)
5026992046241
MPN
RCBO-32-30-SPA
Wired
No
Dimensions
Depth
76mm
Height
114mm
Weight
0.17kg
Width
18mm
Downloads
rcbo3230spa-datasheet
Product Information
Lewden 32A 1 Module Single Pole A Class Type B RCBO 6Ka 30mA - RCBO-32-30-SPA
- This RCBO is designed and tested for use with Lewden branded distribution boards
- Residual current circuit breaker with integral overcurrent protection
- Class A
- Single module RCBOs are suitable for use in TN-S,TN-C-S & TT netwrok systems
- For Cables ø - 1-16mm2
- Breaking Capacity - 6
- Trip Curve - B
- Frequency - 50/60Hz
- Poles - 1P +N
- Rated Operating Voltage: 230V
- Rated Current: 32A
- RCD Class: A
- Residual Current: 30mA
- Dimensions (HWD) - 114 x 18 x 76mm
